    ALCON FP-38-300-SM Conduction Cooled Capacitor RoHs Resonant Condensador

    Ask Lasest Price
    Brand Name : GDHY
    Model Number : C411664KTC2151-01
    Certification : SGS,ISO
    Price : PLEASE CONTACT US FOR DETAILS
    Payment Terms : T/T, Western Union, MoneyGram
    Supply Ability : 1000 PCS /MONTH
    Delivery Time : 14 DAYS
    • Product Details
    • Company Profile

    ALCON FP-38-300-SM Conduction Cooled Capacitor RoHs Resonant Condensador

    ALCON FP-38-300-SM Conduction Cooled Capacitor RoHs Resonant CondensadorALCON FP-38-300-SM CONDUCTION COOLED CAPACITOR ROHS COMPLIANT RESONANT CONDESADOR


    Technical Parameter


    Reference StandardsGB/T 3984-2004 IEC 60110.1
    Operating Temperature Range-40℃~+85℃
    Rated Capacitance0.66μF
    Rated Power150kVar
    Rated Voltage600VAC
    Capacity Tolerance±10%
    Test Voltage between Terminals1.5UNAC 10s
    2~3.5UNDC 10s at 25℃±5℃
    Dissipation Factortgδ≤5×10-4 at 25℃±5℃,1kHz
    Insulation ResistanceR•C≥3000s,at 100VDC,25℃±5℃,60s
    Life Expectancy100000h at UN and 70℃,30000h at Urms

    Specification download: C41-TC2.pdf

    Application

    This series product is suitable for Induction Heating, Electric Cars, Medical Imaging, EV Wireless Chargers, Resonant Circuits.

    ● It is also widely used in high power and high frequency resonant devices.


    Feature

    ● Conduction water-cooled

    ● Polypropylene dielectric

    Self-healing

    Maximum operating coretemperature up to 85

    ● Capacitance tolerance ±10%

    ● Low dissipation factor(tgδ), low ESL, low ESR

    ● High voltage, high frequency and high dV/dt,

    ● Can bear large current, excellent heat dissipation


    Product picture

    ALCON FP-38-300-SM Conduction Cooled Capacitor RoHs Resonant CondensadorALCON FP-38-300-SM Conduction Cooled Capacitor RoHs Resonant Condensador

    Product Shape

    ALCON FP-38-300-SM Conduction Cooled Capacitor RoHs Resonant Condensador


    Workshop&Equipment

    ALCON FP-38-300-SM Conduction Cooled Capacitor RoHs Resonant Condensador

    Prodcution

    ALCON FP-38-300-SM Conduction Cooled Capacitor RoHs Resonant Condensador


    Packing

    ALCON FP-38-300-SM Conduction Cooled Capacitor RoHs Resonant Condensador


    Exhibition

    ALCON FP-38-300-SM Conduction Cooled Capacitor RoHs Resonant Condensador

    Certification

    ALCON FP-38-300-SM Conduction Cooled Capacitor RoHs Resonant Condensador


    Comparison

    ALCON FP-38-300-SM Conduction Cooled Capacitor RoHs Resonant Condensador
