    8UF 800V DC LINK Film Capacitors Myla Tape Packaging Epoxy Resin Seal

    Ask Lasest Price
    Brand Name : GDHY
    Model Number : C53801805JPI01-01
    Certification : SGS,ISO
    Price : PLEASE CONTACT US FOR THE DETAILS
    Payment Terms : T/T, Western Union, MoneyGram
    Supply Ability : 1000PCS/MONTH
    Delivery Time : 14DAYS
    • Product Details
    • Company Profile

    8UF 800V DC LINK Film Capacitors Myla Tape Packaging Epoxy Resin Seal

    8UF 800V DC LINK Film Capacitors Myla Tape Packaging Epoxy Resin Seal8UF/800VDC LINK FILM CAPACITOR MYLA TAPE PACKAGING EPOXY RESIN COATING


    Technical Parameter

    Reference StandardsGB/T 17702, IEC 61071
    Operating Temperature Range-40℃~70℃ TOP max: +85
    Capacitance8μF
    Rated Voltage800VDC
    Capacity Tolerance±5%(J); ±10%(K)
    Test Voltage between Terminals1.5UN(DC)60S 25℃±5℃
    Test Voltage btw Terminals & Case1000+2×UN/√2(VAC) 50Hz 60S (min 3000VAC)
    Dissipation Factortgδ≤1.5×10-3 at 25℃±5℃,100Hz
    Insulation ResistanceC•R≥5000S,at 100VDC,25℃±5℃,60S
    Life Expectancy100000h at Ur and ≤70℃

    Application


    ● This product is widely used in DC-Link Circuits, as a high frequency filtering and decoupling.

    Direct coupling in Power Electronic Equipment

    ● Ups, Inverter Power Supplies, Welder Power Supplies, etc.


    Feature


    ● Polypropylene film dielectric

    ● Myla tape packaging, flame retardant epoxy resin encapsulation

    ● Easy installation

    ● High pulse current withstand capacity

    ● Good high frequency and high current bearing capacity


    Datasheet: C53.pdf


    Product Picture


    8UF 800V DC LINK Film Capacitors Myla Tape Packaging Epoxy Resin Seal8UF 800V DC LINK Film Capacitors Myla Tape Packaging Epoxy Resin Seal


    Production Shape

    8UF 800V DC LINK Film Capacitors Myla Tape Packaging Epoxy Resin Seal


    Production Process


    8UF 800V DC LINK Film Capacitors Myla Tape Packaging Epoxy Resin Seal


    Workshop& Equipment


    8UF 800V DC LINK Film Capacitors Myla Tape Packaging Epoxy Resin Seal


    Company Exhibition


    8UF 800V DC LINK Film Capacitors Myla Tape Packaging Epoxy Resin Seal


    Certification


    8UF 800V DC LINK Film Capacitors Myla Tape Packaging Epoxy Resin Seal


    Packing Method


    8UF 800V DC LINK Film Capacitors Myla Tape Packaging Epoxy Resin Seal
