    CBB81 682J1600V P15 Polypropylene Film Capacitor Condensador Electric Mosquito Swatters

    Ask Lasest Price
    Brand Name : GDHY
    Model Number : CBB81 682J1600V P15
    Certification : SGS,ISO
    Price : PLEASE CONTACT US FOR MORE DETAILS
    Payment Terms : Western Union, T/T, MoneyGram
    Supply Ability : 1KK PCS/MONTH
    Delivery Time : 15 WORKING DAYS
    • Product Details
    • Company Profile

    CBB81 682J1600V P15 Polypropylene Film Capacitor Condensador Electric Mosquito Swatters

    CBB81 682J1600V P15 Polypropylene Film Capacitor Condensador Electric Mosquito SwattersCBB81 682J1600V P15 POLYPROPYLENE FILM CAPACITOR ELECTRIC MOSQUITO SWATTERS HIGH CURRENT CIRCUITS

    Technical Parameter


    Model numberT6821600-D-15-1R
    Reference StandardsGB/T 14579(IEC 60384-17)
    Climate Category40/085/21
    Operating Temperature Range-40℃ to +85℃, Tmax 105℃
    Capacity0.0068UF/682
    Rated Voltage1600V
    Pitch15MM
    Dimension (W*H*T)18*7.5*11.5MM
    Capacity Tolerance±5%(J);±10%(K)
    Withstand voltageVt-t:1.75UN 5S (at20 ±5%)
    Dissipation Factortgδ≤0.0010 (20℃, 1KHz)
    Maximum Pulse Rise Time (dv/dt)30000(V/μS)
    Insulation Resistance>50000MΩ (at 20℃ 1Min)

    Specification download: CBB81.pdf


    Application


    ● Widely used in high-frequency DC/AC and pulse circuits.

    Ideal for high pulse and high current circuits, such as CRT deflection for R-F generators and pulse-forming networks.

    Can be applied in AC/Motor, power, lighting, air conditioner, high voltage, fan, automobile, display, color TV reverse circuits.


    Feature


    ● Metallized polypropylene film foil dielectric

    Non-inductively wound.

    ● Excellent frequency and temperature characteristics.

    ● High-insulation resistance, self-healing effect.

    ● With copper-clad steel and epoxy resin coating.

    ● High stability of capacitance.

    ● Resistance to high voltage, small tgδ and inherent temperature rise

    Good performance


    Product Picture


    CBB81 682J1600V P15 Polypropylene Film Capacitor Condensador Electric Mosquito SwattersCBB81 682J1600V P15 Polypropylene Film Capacitor Condensador Electric Mosquito Swatters


    Product Shape


    CBB81 682J1600V P15 Polypropylene Film Capacitor Condensador Electric Mosquito Swatters


    Production

    CBB81 682J1600V P15 Polypropylene Film Capacitor Condensador Electric Mosquito Swatters


    Workshop&Equipment

    CBB81 682J1600V P15 Polypropylene Film Capacitor Condensador Electric Mosquito Swatters


    Packing method

    CBB81 682J1600V P15 Polypropylene Film Capacitor Condensador Electric Mosquito Swatters

    Certificate

    CBB81 682J1600V P15 Polypropylene Film Capacitor Condensador Electric Mosquito Swatters

    Exhibition
