    ALCON FP-3-400 0.25UF 1000V Conduction Cooled Capacitor

    Ask Lasest Price
    Brand Name : GDHY
    Model Number : C41102254KBC5301-01
    Certification : SGS,ISO
    Price : PLEASE CONTACT US FOR DETAILS
    Payment Terms : Western Union, T/T, MoneyGram
    Supply Ability : 1000PCS/MONTH
    Delivery Time : 15 WORKING DAYS
    • Product Details
    • Company Profile

    ALCON FP-3-400 0.25UF 1000V Conduction Cooled Capacitor

    ALCON FP-3-400 0.25UF 1000V Conduction Cooled CapacitorC41-BC5 0.25UF 1000V POWER FILM CAPACITORS (ALCON FP-3-400) RESONANT CIRCUITS BETTER PERFORMANCE


    Technical Parameter


    Reference StandardsGB/T 3984-2004 IEC 60110.1
    Capacitance0.25μF/254
    Rated capacitance100kVar-1500kVar
    Rated Voltage1000VAC
    Operating Temperature Range-40℃~+85℃
    Tolerance±5%/±10%
    Test Voltage between Terminals1.5UNAC 10s
    2~3.5UNDC 10s at 25℃±5℃
    Dissipation Factortgδ≤5×10-4 at 25℃±5℃,1kHz
    Insulation ResistanceR•C≥3000s,at 100VDC,25℃±5℃,60s
    Life Expectancy100000h at UN and 70℃,30000h at Urms

    Specification download: C41-BC5.pdf


    Application


    Widely used in high power and high frequency resonant devices.

    Standard applications: Induction heating, hear treatment, plasma applications, medical imaging, wireless power transfer, EV charging, IPT, high frequency inverters, high frequency and high ripple current applications like high frequency PWM inverters, high KVA Online UPS, etc.


    Feature


    ● Polypropylene Conduction-cooled capacitor

    High power self-healing capacitor

    ● Low dissipation factor(tgδ), low ESL/ESR

    ● High voltage, frequency and dV/dt

    ● Excellent heat dissipation, high current resistance

    ● Maximum operating core temperature 85


    Product Picture


    ALCON FP-3-400 0.25UF 1000V Conduction Cooled CapacitorALCON FP-3-400 0.25UF 1000V Conduction Cooled Capacitor

    Product Shape


    C41-BC5 0.33UF/700Vrms/300Kvar for induction heating (FP-8-300-4H/Celem CSP305B)High Frequency Capacitor 1


    Production

    ALCON FP-3-400 0.25UF 1000V Conduction Cooled Capacitor


    Workshop&Equipment

    ALCON FP-3-400 0.25UF 1000V Conduction Cooled Capacitor


    Packing method

    MKP-X2 0.33UF/310V P22.5 WIMA FKP 2/FKP 3 KEMET R4631/R463R/R463W/R463N TDK B32669 VISHAY F339M-X2 SAFETY CAPACITOR 5

    Certificate

    ALCON FP-3-400 0.25UF 1000V Conduction Cooled Capacitor

    Exhibition

    MKP-X2 0.33UF/310V P22.5 WIMA FKP 2/FKP 3 KEMET R4631/R463R/R463W/R463N TDK B32669 VISHAY F339M-X2 SAFETY CAPACITOR 7
