    10UF 700V High Frequency Capacitor Induction Heating FP-11-500 Celem C500T

    Ask Lasest Price
    Brand Name : GDHY
    Model Number : C41701106KBE2501-01
    Certification : SGS,ISO
    Price : USD 86 / PCS
    Payment Terms : T/T, Western Union, MoneyGram
    Supply Ability : 1000 PCS/MONTH
    Delivery Time : 14 DAYS
    • Product Details
    • Company Profile

    10UF 700V High Frequency Capacitor Induction Heating FP-11-500 Celem C500T

    10UF 700V High Frequency Capacitor Induction Heating FP-11-500 Celem C500TC41-BE2 10UF/700V/500KVAR INDUCTION HEATING AUTOMOTIVE WIRELESS ALCON FP-11-500/CELEM C500T


    Technical Parameter


    Reference StandardsGB/T 3984-2004 IEC 60110.1
    Operating Temperature Range-40℃~+85
    Capacity Range10μF/106
    Rated Power100kVar-1500kVar
    Rated Voltage700VAC
    Capacity Tolerance±5% ±10%
    Test Voltage between Terminals1.5UNAC 10s
    2~3.5UNDC 10s at 25℃±5℃
    Dissipation Factortgδ≤5×10-4 at 25℃±5℃,1kHz
    Insulation ResistanceR•C≥3000s,at 100VDC,25℃±5℃,60s
    Life Expectancy100000h at UN and 70℃,30000h at Urms

    Specification download: C41-BE1.pdf

    Application


    Used in high power induction heating system. For LC resonance.

    Resonant ciucuits, medical imaging, heat treatment, plasma applications, wireless power transfer, EV (electric vehicle) charging, IPT, high frequency inverters,etc.


    Features

    ● Conduction water-cooled

    ● Polypropylene dielectric

    ● Low dissipation factor(tgδ), low ESL, low ESR

    ● High voltage, high frequency and high dV/dt,

    ● Can bear large current, excellent heat dissipation


    Product picture

    10UF 700V High Frequency Capacitor Induction Heating FP-11-500 Celem C500T10UF 700V High Frequency Capacitor Induction Heating FP-11-500 Celem C500T


    Product shape

    10UF 700V High Frequency Capacitor Induction Heating FP-11-500 Celem C500T

    Production Line

    10UF 700V High Frequency Capacitor Induction Heating FP-11-500 Celem C500T


    Workshop & Equipment

    10UF 700V High Frequency Capacitor Induction Heating FP-11-500 Celem C500T


    Exhibition

    10UF 700V High Frequency Capacitor Induction Heating FP-11-500 Celem C500T


    Certification

    10UF 700V High Frequency Capacitor Induction Heating FP-11-500 Celem C500T


    Packing method


    10UF 700V High Frequency Capacitor Induction Heating FP-11-500 Celem C500T
