C52 1.2UF 125J 400V DC LINK Film Capacitors With 2 PIN Electric Vehicle TDK B32778m Inverter Welder

Guangdong Huayu Electronic Company Limited
Contact Now
    Buy cheap C52 1.2UF 125J 400V DC LINK Film Capacitors With 2 PIN Electric Vehicle TDK B32778m Inverter Welder from wholesalers

    Buy cheap C52 1.2UF 125J 400V DC LINK Film Capacitors With 2 PIN Electric Vehicle TDK B32778m Inverter Welder from wholesalers
    • Buy cheap C52 1.2UF 125J 400V DC LINK Film Capacitors With 2 PIN Electric Vehicle TDK B32778m Inverter Welder from wholesalers
    • Buy cheap C52 1.2UF 125J 400V DC LINK Film Capacitors With 2 PIN Electric Vehicle TDK B32778m Inverter Welder from wholesalers
    • Buy cheap C52 1.2UF 125J 400V DC LINK Film Capacitors With 2 PIN Electric Vehicle TDK B32778m Inverter Welder from wholesalers

    C52 1.2UF 125J 400V DC LINK Film Capacitors With 2 PIN Electric Vehicle TDK B32778m Inverter Welder

    Ask Lasest Price
    Brand Name : GDHY
    Model Number : C52 1.2UF/400V
    Certification : ISO,SGS
    Price : PLEASE CONTACT US FOR DETAILS
    Payment Terms : T/T, Western Union, MoneyGram
    Supply Ability : MORE THAN 1KPCS/MONTH
    Delivery Time : 15 WORKING DAYS
    • Product Details
    • Company Profile

    C52 1.2UF 125J 400V DC LINK Film Capacitors With 2 PIN Electric Vehicle TDK B32778m Inverter Welder

    C52 1.2UF 125J 400V DC LINK Film Capacitors With 2 PIN Electric Vehicle TDK B32778m Inverter WelderDC LINK FILM CAPACITOR 1.2UF 400V FILTERING EV CHARGER NOTOR DRIVE (SIMILAR AS TDK B32778M)


    Technical Parameter


    Model codeC52401125JX08-01
    Capacitance1.2μF/125
    Rated Voltage400V
    Reference StandardsGB/T 17702 IEC 61071
    Operating Temperature Range-40℃~70℃ Tmax 105℃
    Capacity Tolerance±5%(J);±10%(K)
    Dissipation Factortgδ≤1.5X 10-3 ( at25℃±5℃, 100Hz)
    Insulation ResistanceC•R≥5000S (at100VDC,at25℃±5℃,1Min)
    Test voltage between electrodes1.5Un(DC) 60S 25℃±5℃
    Test voltage between electrode and case1000+2 X Un/2(VAC) 50Hz 60s (min 3000VAC)
    Flame retardationUL94V-0
    Life Expectancy100000h at UN and ≤70℃

    Datasheet download: C52.pdf


    Application


    ● Widely used in DC-LINK circuit for filtering energy storage

    ● Can replace electrolytic capacitors, better performance and longer life

    ● Solar/wind inverter; EV/HEV, converters

    SVG, welding machine, induction heating equipment, power supply

    ● Wind turbine energy generators, pure electric and hybrid cars, charging pile, UPS, etc.


    Feature


    ● Polypropylene film dielectric

    ● Plastic shell coating, dry resin infusion

    ● Easy installation

    ● Leads with Tinned copper wire, small size

    ● High pulse current and high dv/dt; low ESL/ESR

    ● High safety, self-healing and self-protecting function built in

    ● Stable capacitance at THB conditions


    Product Picture


    C52 1.2UF 125J 400V DC LINK Film Capacitors With 2 PIN Electric Vehicle TDK B32778m Inverter WelderC52 1.2UF 125J 400V DC LINK Film Capacitors With 2 PIN Electric Vehicle TDK B32778m Inverter WelderC52 1.2UF 125J 400V DC LINK Film Capacitors With 2 PIN Electric Vehicle TDK B32778m Inverter Welder


    Production Shape

    C52 1.2UF 125J 400V DC LINK Film Capacitors With 2 PIN Electric Vehicle TDK B32778m Inverter Welder


    Production Process


    C52 1.2UF 125J 400V DC LINK Film Capacitors With 2 PIN Electric Vehicle TDK B32778m Inverter Welder


    Workshop& Equipment


    C52 1.2UF 125J 400V DC LINK Film Capacitors With 2 PIN Electric Vehicle TDK B32778m Inverter Welder


    Company Exhibition


    C52 1.2UF 125J 400V DC LINK Film Capacitors With 2 PIN Electric Vehicle TDK B32778m Inverter Welder


    Certification


    C52 1.2UF 125J 400V DC LINK Film Capacitors With 2 PIN Electric Vehicle TDK B32778m Inverter Welder


    Packing Method


    C52 1.2UF 125J 400V DC LINK Film Capacitors With 2 PIN Electric Vehicle TDK B32778m Inverter Welder
