    C52 3.3uf 400v DC LINK Film Capacitors TDK B32778m

    Ask Lasest Price
    Brand Name : GDHY
    Model Number : C52 3.3UF/400V
    Certification : ISO,SGS
    Price : PLEASE CONTACT US FOR DETAILS
    Payment Terms : T/T, Western Union, MoneyGram
    Supply Ability : MORE THAN 1KPCS/MONTH
    Delivery Time : 15 WORKING DAYS
    • Product Details
    • Company Profile

    C52 3.3uf 400v DC LINK Film Capacitors TDK B32778m

    CUSTOMIZABLE METALLIZED POLYPROPYLENE FILM CAPACITORS (MKP) C52 3.3UF 400V (SAME AS TDK DC LINK CAPACITORS B32778M) CHARGING PILE


    Technical Parameter


    Model codeC52401335JX10-01
    Capacitance3.3μF
    Rated Voltage400V
    Reference StandardsGB/T 17702 IEC 61071
    Operating Temperature Range-40℃~70℃ Tmax 105℃
    Capacity Tolerance±5%(J)
    Dissipation Factortgδ≤1.5X 10-3 ( at25℃±5℃, 100Hz)
    Insulation ResistanceC•R≥5000S (at100VDC,at25℃±5℃,1Min)
    Flame retardationUL94V-0
    Life Expectancy100000h at UN and ≤70℃

    Datasheet download:C52.pdf


    Application


    ● This product is designed for DC-Link circuits to store energy. For example, in electric vehicle applications, the DC link capacitor is used as a load-balacing energy storage device.

    ● The performance of this product is better than electrolytic capacitors, and its life expectancy is longer.

    ● Also used in UPS, all kinds of frequency converter and inverter power supply; Pure electric and hybrid cars, etc.


    Feature


    ● Polypropylene film dielectric

    ● Plastic shell coating, dry resin infusion

    ● Tinned copper wire

    ● High pulse current and high dv/dt; low ESL/ESR

    ● Small szie, easy installation

    ● Stabe performance, long life.


    Product Picture


    C52 3.3uf 400v DC LINK Film Capacitors TDK B32778m


    Production Shape

    C52 3.3uf 400v DC LINK Film Capacitors TDK B32778m


    Production Process


    C52 3.3uf 400v DC LINK Film Capacitors TDK B32778m


    Workshop& Equipment


    C52 3.3uf 400v DC LINK Film Capacitors TDK B32778m


    Company Exhibition


    C52 3.3uf 400v DC LINK Film Capacitors TDK B32778m


    Certification


    C52 3.3uf 400v DC LINK Film Capacitors TDK B32778m


    Packing Method


    C52 3.3uf 400v DC LINK Film Capacitors TDK B32778m
