    CBB22 Film Capacitor 0.1UF 104j250v P=10mm Free Sample Available

    Ask Lasest Price
    Brand Name : GDHY
    Model Number : CBB22 0.1UF 250V P10
    Certification : SGS,ISO
    Price : PLEASE CONTACT US FOR MORE DETAILS
    Payment Terms : Western Union, T/T, MoneyGram
    Supply Ability : 1KK PCS/MONTH
    Delivery Time : 15 WORKING DAYS
    • Product Details
    • Company Profile

    CBB22 Film Capacitor 0.1UF 104j250v P=10mm Free Sample Available

    CBB22 Film Capacitor 0.1UF 104j250v P=10mm Free Sample AvailableMETALLIZED POLYPROPYLENE FILM CAPACITOR CBB22 0.10UF 104/250V 5% MANUFACTURER

    Technical Parameter


    Reference StandardsGB/T 10190(IEC 60384-16)
    Capacitance0.10μF
    Rated Voltage250VDC
    Pitch10MM
    EncapsulationPowder
    Climate Category40/085/21
    Operating Temperature Range-40℃~85
    Tolerance±5%(J);±10%(K)
    Withstand voltageVt-t:1.6UN 5S (at20 ±5%)
    Dissipation Factor (DF)tgδ≤0.0010 (20, 1KHz)
    Insulation ResistanceC≤0.33μF R≥30000MΩ (at20℃ 100VDC 1Min)
    Maximum Pulse Rise Time (dv/dt)220(V/μS)

    Specification download: CBB22.pdf


    Application


    This series product is designed for high frequency, direct current, AC, Pulse Circuits, and the S-correction circuits of the display device, etc.


    Feature


    ● Metallized polypropylene film dielectric

    ● Non-inductive winding structure

    ● Flame retardant epoxy resin powder encapsulation

    ● Resistance to high voltage, small tgδ, low temperature rise

    ● Datasheet available, customizable products available on request

    ● Good appearance consistency


    Product Picture


    CBB22 Film Capacitor 0.1UF 104j250v P=10mm Free Sample AvailableCBB22 Film Capacitor 0.1UF 104j250v P=10mm Free Sample Available


    Product Shape


    CBB22 Film Capacitor 0.1UF 104j250v P=10mm Free Sample Available


    Production

    CBB22 Film Capacitor 0.1UF 104j250v P=10mm Free Sample Available


    Workshop&Equipment

    CBB22 Film Capacitor 0.1UF 104j250v P=10mm Free Sample Available


    Packing method

    CBB22 Film Capacitor 0.1UF 104j250v P=10mm Free Sample Available

    Certificate

    CBB22 Film Capacitor 0.1UF 104j250v P=10mm Free Sample Available

    Exhibition

    MKP-X2 0.33UF/310V P22.5 WIMA FKP 2/FKP 3 KEMET R4631/R463R/R463W/R463N TDK B32669 VISHAY F339M-X2 SAFETY CAPACITOR 7
