Metallized Polypropylene Film Capacitor CBB22 154j250v 0.15uf P10

    Buy cheap Metallized Polypropylene Film Capacitor CBB22 154j250v 0.15uf P10 from wholesalers

    Buy cheap Metallized Polypropylene Film Capacitor CBB22 154j250v 0.15uf P10 from wholesalers
    • Buy cheap Metallized Polypropylene Film Capacitor CBB22 154j250v 0.15uf P10 from wholesalers
    • Buy cheap Metallized Polypropylene Film Capacitor CBB22 154j250v 0.15uf P10 from wholesalers

    Metallized Polypropylene Film Capacitor CBB22 154j250v 0.15uf P10

    Ask Lasest Price
    Brand Name : GDHY
    Model Number : CBB22 154J250V P10
    Certification : SGS,ISO
    Price : PLEASE CONTACT US FOR MORE DETAILS
    Payment Terms : Western Union, T/T, MoneyGram
    Supply Ability : 1KK PCS/MONTH
    Delivery Time : 15 WORKING DAYS
    • Product Details
    • Company Profile

    Metallized Polypropylene Film Capacitor CBB22 154j250v 0.15uf P10

    Metallized Polypropylene Film Capacitor CBB22 154j250v 0.15uf P100.15UF 250V 5% CBB22 METALLIZED POLYPROPYLENE FILM CAPACITOR FREE SAMPLE AVAILABLE

    Technical Parameter


    Reference StandardsGB/T 10190(IEC 60384-16)
    Climate Category40/085/21
    Operating Temperature Range-40℃~85
    Capacity Range0.15μF
    Rated Voltage250VDC
    Pitch10MM
    Capacity Tolerance±5%(J);±10%(K)
    Withstand voltageVt-t:1.6UN 5S (at20 ±5%)
    Dissipation Factortgδ≤0.0010 (20, 1KHz)
    Insulation ResistanceC≤0.33μF R≥30000MΩ (at20℃ 100VDC 1Min)
    Maximum Pulse Rise Time (dv/dt)220(V/μS)

    Specification download: CBB22.pdf


    Application


    Widely used in high frequency, DC, AC, Pulse Circuits, and the S-correction circuits of the display device.


    Feature


    ● Metallized polypropylene film dielectric

    ● Non-inductive winding structure

    ● Flame retardant epoxy resin powder encapsulation

    ● Resistance to high voltage, small tgδ, low temperature rise


    Product Picture


    Metallized Polypropylene Film Capacitor CBB22 154j250v 0.15uf P10


    Product Shape


    Metallized Polypropylene Film Capacitor CBB22 154j250v 0.15uf P10


    Production

    Metallized Polypropylene Film Capacitor CBB22 154j250v 0.15uf P10


    Workshop&Equipment

    Metallized Polypropylene Film Capacitor CBB22 154j250v 0.15uf P10


    Packing method

    Metallized Polypropylene Film Capacitor CBB22 154j250v 0.15uf P10

    Certificate

    Metallized Polypropylene Film Capacitor CBB22 154j250v 0.15uf P10

    Exhibition
