    High Frequency Metalized Film Water Cooled Capacitor 0.20UF 3000V 200kVar

    Ask Lasest Price
    Brand Name : GDHY
    Model Number : C41302204KBA1201-01
    Certification : SGS,ISO
    Price : PLEASE CONTACT US FOR DETAILS
    Payment Terms : L/C, T/T, Western Union, MoneyGram
    Supply Ability : 1000PCS/MONTH
    Delivery Time : 15 WORKING DAYS
    • Product Details
    • Company Profile

    High Frequency Metalized Film Water Cooled Capacitor 0.20UF 3000V 200kVar

    High Frequency Metalized Film Water Cooled Capacitor 0.20UF 3000V 200kVar C41-BA1 0.20UF 3000VAC 200KVAR METALIZED FILM WATER COOLING RESONANT CAPACITOR


    Technical Parameter

    Reference standardsGB/T 3984-2004 IEC 60110.1
    Capacitance range0.20μF
    Rated capacitance200kVar
    Rated voltage3000VAC
    Operating temperature range-40℃~+85℃
    Dissipation factortgδ≤5×10-4
    at 25℃±5℃,1kHz
    Tolerance±10%
    Test voltage between terminals1.5UNAC 10s
    3.5UNDC 10s at 25℃±5℃
    Insulation resistanceR·C≥3000s,at 100VDC,25℃±5℃,60s
    Life expectancy100000h at UN and 70℃,30000h at Urms

    Download specification: C41-BA1.pdf



    Application

    This product is widely used in high power and high frequency resonant devices, such as induction heating, heat treatment, resonant circuits, EV (electric vehicle) charging, medical imaging, wireless power transfer, IPT, high frequency inverters, etc.


    Features


    ● Conduction water cooling

    ● Polypropylene as the medium

    ● Imported copper foil

    ● High quality and excellent performance
    ● Withstand high current, high voltage, high frequency, and high dv/dt


    Product Picture

    High Frequency Metalized Film Water Cooled Capacitor 0.20UF 3000V 200kVarHigh Frequency Metalized Film Water Cooled Capacitor 0.20UF 3000V 200kVar


    Product Shape

    High Frequency Metalized Film Water Cooled Capacitor 0.20UF 3000V 200kVar


    Workshop&Equipment

    High Frequency Metalized Film Water Cooled Capacitor 0.20UF 3000V 200kVar


    Certification

    High Frequency Metalized Film Water Cooled Capacitor 0.20UF 3000V 200kVar


    Exhibition

    High Frequency Metalized Film Water Cooled Capacitor 0.20UF 3000V 200kVar


    Packing Method

    High Frequency Metalized Film Water Cooled Capacitor 0.20UF 3000V 200kVar

    High Frequency Metalized Film Water Cooled Capacitor 0.20UF 3000V 200kVar
