    223J400V P10 MPP Film Capacitor Kapasitor Polypropylene Condensateur CBB22 Noise Suppression

    Ask Lasest Price
    Brand Name : GDHY
    Model Number : CBB22 223J400V P10
    Certification : SGS,ISO
    Price : PLEASE CONTACT US FOR MORE DETAILS
    Payment Terms : Western Union, T/T, MoneyGram
    Supply Ability : 1KK PCS/MONTH
    Delivery Time : 15 WORKING DAYS
    • Product Details
    • Company Profile

    223J400V P10 MPP Film Capacitor Kapasitor Polypropylene Condensateur CBB22 Noise Suppression

    223J400V P10 MPP Film Capacitor Kapasitor Polypropylene Condensateur CBB22 Noise SuppressionCBB POLYPROPYLENE FILM CAPACITOR 223J400V METALLIZED FILTER NOISE SUPPRESSION

    Technical Parameter


    Model numberB2230400-D-10-1R
    Reference StandardsGB/T 10190(IEC 60384-16)
    Climate Category40/085/21
    Operating Temperature Rangefrom -40℃ to +85℃
    Capacity0.022μF
    Rated Voltage400V
    Pitch10mm
    Dimension (W*H*T)Max 13.0*6.5*10.5mm
    Capacity Tolerance±5%(J);±10%(K)
    Withstand voltageVt-t:1.6UN 5S (at20 ±5%)
    Dissipation Factortgδ≤0.0010 (20, 1KHz)
    Maximum Pulse Rise Time (dv/dt)330(V/μS)
    Insulation ResistanceR>100000MΩ (at 20 100VDC 1Min)

    Specification download: CBB22.pdf


    Application


    Suitable for low-pulse circuits, frequency and current circuits, general resonance circuit and the S-shaping correction circuits of the display device.

    Widely used in filter and noise suppression, Lighting industry, Automation industry, Power industry, Household appliance, Telecommunication industry.


    Feature


    ● Low DF and high IR

    Non-inductive winding structure, epoxy resin coating

    ● High stability of capacitance and reliability, high insulation resistance

    ● Good self-healing

    ● Resistance to high voltage, small tgδ and inherent temperature rise


    Product Picture
