    0.66UF 700V Water Cooled Capacitors C41 High Power High Thermal Withstand Inductive Heating

    Ask Lasest Price
    Brand Name : GDHY
    Model Number : C41701664KBB2301-01
    Certification : SGS,ISO
    Price : PLEASE CONTACT US FOR DETAILS
    Payment Terms : Western Union, MoneyGram, T/T
    Supply Ability : 1000 PCS / MONTH
    Delivery Time : 14 DAYS
    • Product Details
    • Company Profile

    0.66UF 700V Water Cooled Capacitors C41 High Power High Thermal Withstand Inductive Heating

    0.66UF 700V Water Cooled Capacitors C41 High Power High Thermal Withstand Inductive HeatingWATER COOLING CAPACITOR 0.66UF 664 700V HIGH FREQUENCY HIGH POWER RESONANT CAP


    Technical Parameter


    Reference StandardsGB/T 3984-2004 IEC 60110.1
    Capacity0.66μF
    Rated Voltage700Vrms
    Model NumberC41701664KBB2301-01
    Max Power300kVar
    Capacity Tolerance±10%
    ESR mΩ0.8 mΩ
    Operating Temperature Range-40℃~+85℃
    Dimension80*80*36mm
    Test Voltage between Terminals1.5UNAC 10s
    3.5UNDC 10s at 25℃±5℃
    Dissipation Factortgδ≤5×10-4 at 25℃±5℃,1kHz
    Insulation ResistanceR•C≥3000s,at 100VDC,25℃±5℃,60s
    Life Expectancy100000h at UN and 70℃,30000h at Urms

    Application


    Widely used in high power and high frequency resonant devices.

    Can be used in applications including induction heating, RF Amplifiers, welding equipment, heat treatment, medical imaging, wireless charging , electric vehicle charging, etc.

    For replace Celem power capacitors.


    Feature


    ● Conduction cooled

    ● Low dissipation factor(tgδ), ESL and ESR

    ● High voltage, high frequency and high dV/dt; high current resistance

    ● Excellent heat dissipation

    ● Self healing, maximum operating core temperature 85

    ● High thermal withstand capacity

    ● Threaded hole for mounting on bus-bar


    Product Picture

    0.66UF 700V Water Cooled Capacitors C41 High Power High Thermal Withstand Inductive Heating0.66UF 700V Water Cooled Capacitors C41 High Power High Thermal Withstand Inductive Heating


    Product shape

    0.66UF 700V Water Cooled Capacitors C41 High Power High Thermal Withstand Inductive Heating


    Production

    0.66UF 700V Water Cooled Capacitors C41 High Power High Thermal Withstand Inductive Heating


    Workshop& Equipment

    0.66UF 700V Water Cooled Capacitors C41 High Power High Thermal Withstand Inductive Heating


    Packing method

    0.66UF 700V Water Cooled Capacitors C41 High Power High Thermal Withstand Inductive Heating

    Certificate

    0.66UF 700V Water Cooled Capacitors C41 High Power High Thermal Withstand Inductive Heating

    Exhibition

    0.66UF 700V Water Cooled Capacitors C41 High Power High Thermal Withstand Inductive Heating
