1000A 6.3UF Conduction Cooled Capacitor ALCON FP-11-500

    Buy cheap 1000A 6.3UF Conduction Cooled Capacitor ALCON FP-11-500 from wholesalers

    Buy cheap 1000A 6.3UF Conduction Cooled Capacitor ALCON FP-11-500 from wholesalers
    • Buy cheap 1000A 6.3UF Conduction Cooled Capacitor ALCON FP-11-500 from wholesalers

    1000A 6.3UF Conduction Cooled Capacitor ALCON FP-11-500

    Ask Lasest Price
    Brand Name : GDHY
    Model Number : C41701635KBE1501-01
    Certification : SGS,ISO
    Price : USD 86 / PCS
    Payment Terms : T/T, Western Union, MoneyGram
    Supply Ability : 1000 PCS/MONTH
    Delivery Time : 14 DAYS
    • Product Details
    • Company Profile

    1000A 6.3UF Conduction Cooled Capacitor ALCON FP-11-500

    C41-BE1 6.3UF/700V/500KVAR ALCON FP-11-500/CELEM C500T CONDUCTION-COOLED CAPACITOR CAPACITOR MANUFACTURING COMPANIES


    Technical Parameter

    Reference StandardsGB/T 3984-2004 IEC 60110.1
    Operating Temperature Range-40℃~85℃
    Capacity Range1.2-21μF
    Rated Power500kVar
    Rated Voltage400-1100VAC
    Capacity Tolerance±10%
    Test Voltage between Terminals1.5UNAC 10s
    2~3.5UNDC 10s at 25℃±5℃
    Dissipation Factortgδ≤5×10-4 at 25℃±5℃,1kHz
    Insulation ResistanceR•C≥3000s,at 100VDC,25℃±5℃,60s
    Life Expectancy100000h at UN and 70℃,30000h at Urms

    Specification download:C41-BE1.pdf


    Application

    Induction heating, heat treatment, plasma applications, resonant circuits, medical imaging, wireless power transfer, EV (electric vehicle) charging, IPT, high frequency inverters,etc.


    Features

    ● Conduction water-cooled

    ● Polypropylene dielectric

    ● Low dissipation factor(tgδ), low ESL, low ESR

    ● High voltage, high frequency and high dV/dt,

    ● Can bear large current, excellent heat dissipation


    Product picture

    1000A 6.3UF Conduction Cooled Capacitor ALCON FP-11-500


    Product shape

    1000A 6.3UF Conduction Cooled Capacitor ALCON FP-11-500

    Production Line

    1000A 6.3UF Conduction Cooled Capacitor ALCON FP-11-500


    Workshop & Equipment

    1000A 6.3UF Conduction Cooled Capacitor ALCON FP-11-500


    Exhibition

    1000A 6.3UF Conduction Cooled Capacitor ALCON FP-11-500


    Certification

    1000A 6.3UF Conduction Cooled Capacitor ALCON FP-11-500


    Packing method


    1000A 6.3UF Conduction Cooled Capacitor ALCON FP-11-500
