Heat Treatment Metallized 600VAC GDHY Polypropylene Film Capacitor

    Buy cheap Heat Treatment Metallized 600VAC GDHY Polypropylene Film Capacitor from wholesalers

    Buy cheap Heat Treatment Metallized 600VAC GDHY Polypropylene Film Capacitor from wholesalers
    • Buy cheap Heat Treatment Metallized 600VAC GDHY Polypropylene Film Capacitor from wholesalers

    Heat Treatment Metallized 600VAC GDHY Polypropylene Film Capacitor

    Ask Lasest Price
    Brand Name : GDHY
    Model Number : C41601404KTC1101-01
    Price : USD187/PC
    Payment Terms : T/T, Western Union, MoneyGram
    Supply Ability : 1000PCS/MONTH
    Delivery Time : 14days
    Certification : SGS,ISO
    • Product Details
    • Company Profile

    Heat Treatment Metallized 600VAC GDHY Polypropylene Film Capacitor

    C41-TC1 0.4uF 600V 100KVar Alcon FP-4N-100 Celem CSM NANO for heat treatment Conduction-cooled Capacitor

    Technical Parameter

    Reference StandardsGB/T 3984-2004 IEC 60110.1
    Operating Temperature Range-40℃~85℃
    Capacity Range0.1μF~0.3μF
    Power Range100kVar
    Rated Voltage400-1100VAC
    Capacity Tolerance±5% ~ ±10%
    Test Voltage between Terminals1.5UNAC 10s
    2~3.5UNDC 10s at 25℃±5℃
    Dissipation Factortgδ≤5×10-4 at 25℃±5℃,1kHz
    Insulation ResistanceR•C≥3000s,at 100VDC,25℃±5℃,60s
    Life Expectancy100000h at UN and 70℃,30000h at Urms

    Application


    Induction heating, heat treatment, plasma applications, resonant circuits, medical imaging, wireless power transfer, EV (electric vehicle) charging, IPT, high frequency inverters,etc.


    Features

    ● Conduction water-cooled

    ● Polypropylene dielectric

    ● Low dissipation factor(tgδ), low ESL, low ESR

    ● High voltage, high frequency and high dV/dt,

    ● Can bear large current, excellent heat dissipation


    Product Picture


    Heat Treatment Metallized 600VAC GDHY Polypropylene Film Capacitor


    Product Shape


    Heat Treatment Metallized 600VAC GDHY Polypropylene Film Capacitor


    Workshop&Equipment


    Heat Treatment Metallized 600VAC GDHY Polypropylene Film Capacitor


    Exhibition


    Heat Treatment Metallized 600VAC GDHY Polypropylene Film Capacitor


    Certification


    Heat Treatment Metallized 600VAC GDHY Polypropylene Film Capacitor


    Packing Method

    Heat Treatment Metallized 600VAC GDHY Polypropylene Film Capacitor
