    GB/T 3984-2004 IEC 60110.1 1100VAC Induction Heater Capacitor

    Ask Lasest Price
    Brand Name : GDHY
    Model Number : C41701174KTC2151-01
    Certification : SGS,ISO
    Price : 107 USD /PCS
    Payment Terms : T/T, Western Union, MoneyGram
    Supply Ability : 1000 PCS/ MONTH
    Delivery Time : 14 DAYS
    • Product Details
    • Company Profile

    GB/T 3984-2004 IEC 60110.1 1100VAC Induction Heater Capacitor

    C41-TC2 0.17UF/700V/150KVAR ALCON FP-4-150-SM/SP CELEM CSM150 Induction Heater Power Consumption Capacitor


    Technical Parameter


    Reference StandardsGB/T 3984-2004 IEC 60110.1
    Operating Temperature Range-40℃~85℃
    Capacity Range0.2-2.4UF
    Power Range150-300 kVar
    Rated Voltage

    400-1100VAC

    Capacity Tolerance±10%
    Test Voltage between Terminals1.5UNAC 10s
    2~3.5UNDC 10s at 25℃±5℃
    Dissipation Factortgδ≤5×10-4 at 25℃±5℃,1kHz
    Insulation ResistanceR•C≥3000s,at 100VDC,25℃±5℃,60s
    Life Expectancy100000h at UN and 70℃,30000h at Urms

    Specification download: C41-TC2.pdf


    Application

    Induction heating, heat treatment, plasma applications, resonant circuits, medical imaging, wireless power transfer, EV (electric vehicle) charging, IPT, high frequency inverters,etc.


    Feature

    ● Conduction water-cooled

    ● Polypropylene dielectric

    ● Low dissipation factor(tgδ), low ESL, low ESR

    ● High voltage, high frequency and high dV/dt,

    ● Can bear large current, excellent heat dissipation


    Product Picture


    GB/T 3984-2004 IEC 60110.1 1100VAC Induction Heater Capacitor


    Product Shape

    GB/T 3984-2004 IEC 60110.1 1100VAC Induction Heater Capacitor

    Production Line

    GB/T 3984-2004 IEC 60110.1 1100VAC Induction Heater Capacitor


    Workshop&Equipment

    GB/T 3984-2004 IEC 60110.1 1100VAC Induction Heater Capacitor

    Packing Method

    GB/T 3984-2004 IEC 60110.1 1100VAC Induction Heater Capacitor


    Certification

    GB/T 3984-2004 IEC 60110.1 1100VAC Induction Heater Capacitor


    Exhibition

    GB/T 3984-2004 IEC 60110.1 1100VAC Induction Heater Capacitor
