    Low ESR 0.1UF 300KVAR Conduction Cooled Capacitor

    Ask Lasest Price
    Brand Name : GDHY
    Model Number : C41102104KTC2151-01
    Certification : SGS,ISO
    Price : 107 USD /PCS
    Payment Terms : T/T, Western Union, MoneyGram
    Supply Ability : 1000 PCS/ MONTH
    Delivery Time : 14 DAYS
    • Product Details
    • Company Profile

    Low ESR 0.1UF 300KVAR Conduction Cooled Capacitor

    C41-TC2 0.1UF/1000V/300KVAR ALCON FP-4-150-SM/SP CELEM CSM150 Induction Heater Manufacturers Capacitor Conduction Cooled Capacitor


    Technical Parameter


    Reference StandardsGB/T 3984-2004 IEC 60110.1
    Operating Temperature Range-40℃~85℃
    Capacity Range0.1μF
    Power Range300 kVar
    Rated Voltage1000VAC
    Capacity Tolerance±10%
    Test Voltage between Terminals1.5UNAC 10s
    2~3.5UNDC 10s at 25℃±5℃
    Dissipation Factortgδ≤5×10-4 at 25℃±5℃,1kHz
    Insulation ResistanceR•C≥3000s,at 100VDC,25℃±5℃,60s
    Life Expectancy100000h at UN and 70℃,30000h at Urms

    Specification download: C41-TC2.pdf


    Application

    Induction heating, heat treatment, plasma applications, resonant circuits, medical imaging, wireless power transfer, EV (electric vehicle) charging, IPT, high frequency inverters,etc.


    Feature

    ● Conduction water-cooled

    ● Polypropylene dielectric

    ● Low dissipation factor(tgδ), low ESL, low ESR

    ● High voltage, high frequency and high dV/dt,

    ● Can bear large current, excellent heat dissipation


    Product Picture


    Low ESR 0.1UF 300KVAR Conduction Cooled Capacitor


    Product Shape

    Low ESR 0.1UF 300KVAR Conduction Cooled Capacitor

    Production Line

    Low ESR 0.1UF 300KVAR Conduction Cooled Capacitor


    Workshop&Equipment

    Low ESR 0.1UF 300KVAR Conduction Cooled Capacitor

    Packing Method

    Low ESR 0.1UF 300KVAR Conduction Cooled Capacitor


    Certification

    Low ESR 0.1UF 300KVAR Conduction Cooled Capacitor


    Exhibition

    Low ESR 0.1UF 300KVAR Conduction Cooled Capacitor
