500V 200KVAR 1.2UF Water Cooled Capacitor ALCON FP-5F-200

    Buy cheap 500V 200KVAR 1.2UF Water Cooled Capacitor ALCON FP-5F-200 from wholesalers

    Buy cheap 500V 200KVAR 1.2UF Water Cooled Capacitor ALCON FP-5F-200 from wholesalers
    • Buy cheap 500V 200KVAR 1.2UF Water Cooled Capacitor ALCON FP-5F-200 from wholesalers
    • Buy cheap 500V 200KVAR 1.2UF Water Cooled Capacitor ALCON FP-5F-200 from wholesalers

    500V 200KVAR 1.2UF Water Cooled Capacitor ALCON FP-5F-200

    Ask Lasest Price
    Brand Name : GDHY
    Model Number : C41501125KBB1201-01
    Certification : SGS,ISO
    Price : USD 60/ PCS
    Payment Terms : Western Union, MoneyGram, T/T
    Supply Ability : 1000 PCS / MONTH
    Delivery Time : 14 DAYS
    • Product Details
    • Company Profile

    500V 200KVAR 1.2UF Water Cooled Capacitor ALCON FP-5F-200

    C41-BB1 1.2UF/500V/200KVAR (ALCON FP-5F-200)WATER COOLING CAPACITOR WATER COOLING CAPACITOR POWER CAPACITOR


    Technical Parameter

    Reference StandardsGB/T 3984-2004 IEC 60110.1
    Operating Temperature Range-40℃~85℃
    Capacity Range1.32μF
    Power Range300kVar
    Rated Voltage600VAC
    Capacity Tolerance±10%
    Test Voltage between Terminals1.5UNAC 10s
    2~3.5UNDC 10s at 25℃±5℃
    Dissipation Factortgδ≤5×10-4 at 25℃±5℃,1kHz
    Insulation ResistanceR•C≥3000s,at 100VDC,25℃±5℃,60s
    Life Expectancy100000h at UN and 70℃,30000h at Urms

    Specification download: C41-BB1.pdf


    Application


    Induction heating, heat treatment, plasma applications, resonant circuits, medical imaging, wireless power transfer, EV (electric vehicle) charging, IPT, high frequency inverters,etc.


    Feature


    ● Conduction water-cooled

    ● Polypropylene dielectric

    ● Low dissipation factor(tgδ), low ESL, low ESR

    ● High voltage, high frequency and high dV/dt

    ● Can bear large current, excellent heat dissipation


    Product Picture

    500V 200KVAR 1.2UF Water Cooled Capacitor ALCON FP-5F-200500V 200KVAR 1.2UF Water Cooled Capacitor ALCON FP-5F-200


    Product shape

    500V 200KVAR 1.2UF Water Cooled Capacitor ALCON FP-5F-200


    Production

    500V 200KVAR 1.2UF Water Cooled Capacitor ALCON FP-5F-200


    Workshop& Equipment

    500V 200KVAR 1.2UF Water Cooled Capacitor ALCON FP-5F-200


    Packing method

    500V 200KVAR 1.2UF Water Cooled Capacitor ALCON FP-5F-200

    Certificate

    500V 200KVAR 1.2UF Water Cooled Capacitor ALCON FP-5F-200

    Exhibition

    500V 200KVAR 1.2UF Water Cooled Capacitor ALCON FP-5F-200
