CBB22 224J400V 0.22uF CBB Polypropylene Film Capacitor

    Buy cheap CBB22 224J400V 0.22uF CBB Polypropylene Film Capacitor from wholesalers

    Buy cheap CBB22 224J400V 0.22uF CBB Polypropylene Film Capacitor from wholesalers
    • Buy cheap CBB22 224J400V 0.22uF CBB Polypropylene Film Capacitor from wholesalers

    CBB22 224J400V 0.22uF CBB Polypropylene Film Capacitor

    Ask Lasest Price
    Brand Name : GDHY
    Model Number : CBB22 224J400V 15
    Certification : SGS,ISO
    Price : USD0.1/PC
    Payment Terms : T/T, Western Union, MoneyGram
    Supply Ability : 1KKpcs/Month
    Delivery Time : 14days
    • Product Details
    • Company Profile

    CBB22 224J400V 0.22uF CBB Polypropylene Film Capacitor

    CBB22 224J400V 0.22UF400V 220nF 400V Pitch P=15mm Polypropylene Film Capacitor CBB22 Capacitor


    Technical Parameter


    Reference StandardsGB/T 10190(IEC 60384-16)
    Climate Category40/085/21
    Operating Temperature Range-40℃~+85℃,Tmax 105
    Capacity Range0.01~2.2μF
    Rated Voltage100V,250V,400V,630V(DC)
    Capacity Tolerance±5%(J);±10%(K);±20%(M)
    Withstand voltage2.0UR 5S (@20±5%)
    Dissipation Factortgδ≤0.0010 (@20℃, 1KHz)
    Insulation Resistance

    ≥30000MΩ(at 20℃ 100VDC 1Min)


    Application


    Widely used in high frequency, direct current and pulse circuits


    Features


    ● Metallized polypropylene inner series structure

    ● Self-healing

    ● It can be bear high voltage

    ● Flame retardant epoxy resin wrapping


    Product Picture


    CBB22 224J400V 0.22uF CBB Polypropylene Film Capacitor


    Product Shape

    CBB22 224J400V 0.22uF CBB Polypropylene Film Capacitor


    Produce Line


    CBB22 224J400V 0.22uF CBB Polypropylene Film Capacitor


    Workshop&Equipment


    CBB22 224J400V 0.22uF CBB Polypropylene Film Capacitor


    Exhibition

    CBB22 224J400V 0.22uF CBB Polypropylene Film Capacitor

    Certification


    CBB22 224J400V 0.22uF CBB Polypropylene Film Capacitor


    Packing Method


    CBB22 224J400V 0.22uF CBB Polypropylene Film Capacitor
