    223J 2KV 0.022uF CBB81 22nF P20 CBB Polypropylene Film Capacitor

    Ask Lasest Price
    Brand Name : GDHY
    Model Number : CBB81 223J2KV 20
    Certification : SGS,ISO
    Price : USD0.1/PC
    Payment Terms : T/T, Western Union, MoneyGram
    Supply Ability : 1KKpcs/Month
    Delivery Time : 14days
    • Product Details
    • Company Profile

    223J 2KV 0.022uF CBB81 22nF P20 CBB Polypropylene Film Capacitor

    CBB capacitor 223 2000V 223J 2KV 0.022uF 22nF P20 CBB81 Metallized Polypropylene Film Capacitor


    Technical Parameter


    Reference StandardsGB/T 14579(IEC 60384-17)
    Climate Category40/085/21
    Operating Temperature Range-40℃~+85℃,Tmax 105
    Capacity Range0.001~0.1μF
    Rated Voltage800V,1000V,1200V,1600V,2000V(DC)
    Capacity Tolerance±5%(J);±10%(K);±20%(M)
    Withstand voltage2.0UR 5S (@20±5%)
    Dissipation Factortgδ≤0.0010 (@20℃, 1KHz)
    Insulation Resistance

    ≥30000MΩ(at 20℃ 100VDC 1Min)


    Application


    Widely used in high frequency, direct current and pulse circuits


    Features


    ● Metallized polypropylene inner series structure

    ● Self-healing

    ● It can be bear high voltage

    ● Flame retardant epoxy resin wrapping


    Product Picture
