    IEC 60384-16 250VDC 2.2UF Metalized Polypropylene Capacitors

    Ask Lasest Price
    Brand Name : GDHY
    Model Number : CBB20 2.2UF 250VDC/XXP 225J250V
    Certification : SGS,ISO
    Price : USD0.8/PC
    Payment Terms : T/T, Western Union, MoneyGram
    Supply Ability : 1KKpcs/Month
    Delivery Time : 14days
    • Product Details
    • Company Profile

    IEC 60384-16 250VDC 2.2UF Metalized Polypropylene Capacitors

    CBB20 2.2UF 250VDC for Audio Frequency Division Circuit Axial Audio Metallized Polypropylene Film Capacitor

    Technical Parameter

    Reference StandardsGB/T 10190(IEC 60384-16)
    Climate Category40/085/21
    Operating Temperature Range-40℃~85℃ Tmax 105
    Capacity Range0.01-40μF
    Rated Voltage250VDC/400VDC/630VDC
    Capacity Tolerance±5%(J);±10%(K);±20%(M)
    Withstand voltage1.6UR (5S)
    Dissipation Factortgδ≤0.0010 (20℃, 1KHz)
    Insulation ResistanceC≤0.33μF R≥100000MΩ(at 20℃ 100VDC 1Min)
    C>0.33 μF RCN≥30000S (at 20℃ 100VDC 1Min)

    Application


    Temperature compensating circuit

    Timing oscillation circuit

    Audio frequency division circuit


    Features


    ● Metallized polypropylene film dielectric

    ● Non-inductive winding structure

    ● Myla tape with flame retardant epoxy resin at both ends

    ● Axial tin copper wire leads

    ● Resistance to high voltage, small tgδ, low temperature rise


    Product Picture

    IEC 60384-16 250VDC 2.2UF Metalized Polypropylene Capacitors

    Product Shape

    IEC 60384-16 250VDC 2.2UF Metalized Polypropylene Capacitors


    Workshop&Equipment


    IEC 60384-16 250VDC 2.2UF Metalized Polypropylene Capacitors


    Exhibitoon


    IEC 60384-16 250VDC 2.2UF Metalized Polypropylene Capacitors

    Certification


    IEC 60384-16 250VDC 2.2UF Metalized Polypropylene Capacitors


    Packign Method


    IEC 60384-16 250VDC 2.2UF Metalized Polypropylene Capacitors
