Alcon FP-20-400 700Vrms 500nF Conduction Cooled Capacitor

    Buy cheap Alcon FP-20-400 700Vrms 500nF Conduction Cooled Capacitor from wholesalers

    Buy cheap Alcon FP-20-400 700Vrms 500nF Conduction Cooled Capacitor from wholesalers
    • Buy cheap Alcon FP-20-400 700Vrms 500nF Conduction Cooled Capacitor from wholesalers
    • Buy cheap Alcon FP-20-400 700Vrms 500nF Conduction Cooled Capacitor from wholesalers

    Alcon FP-20-400 700Vrms 500nF Conduction Cooled Capacitor

    Ask Lasest Price
    Brand Name : GDHY
    Model Number : C41701504KBA2401-01
    Certification : SGS,ISO
    Price : USD55/PC
    Payment Terms : T/T, Western Union, MoneyGram
    Supply Ability : 1000PCS/ MONTH
    Delivery Time : 14days
    • Product Details
    • Company Profile

    Alcon FP-20-400 700Vrms 500nF Conduction Cooled Capacitor

    C41-BA2 0.5uF/700Vrms/400kVar( Alcon FP-20-400/Celem CSP 150/400) Power Film Capacitor for Bolt Heating

    Technical Parameter

    Reference StandardsGB/T 3984-2004 IEC 60110.1
    Operating Temperature Range-40℃~85℃
    Capacity Range0.66μF~2.4μF
    Capacity Range400kVar
    Rated Voltage400-800VAC
    Capacity Tolerance±5% ~ ±10%
    Test Voltage between Terminals1.5UNAC 10s
    2~3.5UNDC 10s at 25℃±5℃
    Dissipation Factortgδ≤5×10-4 at 25℃±5℃,1kHz
    Insulation ResistanceR•C≥3000s,at 100VDC,25℃±5℃,60s
    Life Expectancy100000h at UN and 70℃,30000h at Urms

    Application


    Induction heating, heat treatment, plasma applications, resonant circuits, medical imaging, wireless power transfer, EV (electric vehicle) charging, IPT, high frequency inverters,etc.


    Features


    ● Conduction water-cooled

    ● Polypropylene dielectric

    ● Low dissipation factor(tgδ), low ESL, low ESR

    ● High voltage, high frequency and high dV/dt,

    ● Can bear large current, excellent heat dissipation


    Product Picture


    Alcon FP-20-400 700Vrms 500nF Conduction Cooled CapacitorAlcon FP-20-400 700Vrms 500nF Conduction Cooled Capacitor

    Product Shape


    Alcon FP-20-400 700Vrms 500nF Conduction Cooled Capacitor


    Workshop&Equipment


    Alcon FP-20-400 700Vrms 500nF Conduction Cooled Capacitor


    Certification


    Alcon FP-20-400 700Vrms 500nF Conduction Cooled Capacitor


    Exhibition


    Alcon FP-20-400 700Vrms 500nF Conduction Cooled Capacitor


    Packing Method


    Alcon FP-20-400 700Vrms 500nF Conduction Cooled Capacitor


    Quality Alcon FP-20-400 700Vrms 500nF Conduction Cooled Capacitor for sale
