GB/T 3984-2004 1.2UF 600VAC Power Film Capacitor

    Buy cheap GB/T 3984-2004 1.2UF 600VAC Power Film Capacitor from wholesalers

    Buy cheap GB/T 3984-2004 1.2UF 600VAC Power Film Capacitor from wholesalers
    • Buy cheap GB/T 3984-2004 1.2UF 600VAC Power Film Capacitor from wholesalers

    GB/T 3984-2004 1.2UF 600VAC Power Film Capacitor

    Ask Lasest Price
    Brand Name : GDHY
    Model Number : C41601125KBA1301-01
    Certification : SGS,ISO
    Price : 212 USD/ PCS
    Payment Terms : L/C, T/T, Western Union, MoneyGram
    Supply Ability : 1000PCS/MONTH
    Delivery Time : 14 DAYS
    • Product Details
    • Company Profile

    GB/T 3984-2004 1.2UF 600VAC Power Film Capacitor

    C41-BA1 1.2UF/600V/300KVAR (ALCONFP-7-300/ CELEM CSP150) POWER FILM CAPACITOR VENDORS


    Technical Parameter

    Reference StandardsGB/T 3984-2004 IEC 60110.1
    Operating Temperature Range-40℃~85℃
    Capacity Range0.24-5μF
    Capacity Range300-400kVar
    Rated Voltage400V-1100AC
    Capacity Tolerance±10%
    Test Voltage between Terminals1.5UNAC 10s
    2~3.5UNDC 10s at 25℃±5℃
    Dissipation Factortgδ≤5×10-4 at 25℃±5℃,1kHz
    Insulation ResistanceR•C≥3000s,at 100VDC,25℃±5℃,60s
    Life Expectancy100000h at UN and 70℃,30000h at Urms

    Download specification: C41-BA1.pdf



    Application

    Induction heating, heat treatment, plasma applications, resonant circuits, medical imaging, wireless power transfer, EV (electric vehicle) charging, IPT, high frequency inverters,etc.


    Features


    ● Conduction water-cooled

    ● Polypropylene dielectric

    ● Low dissipation factor(tgδ), low ESL, low ESR

    ● High voltage, high frequency and high dV/dt,

    ● Can bear large current, excellent heat dissipation


    Product Picture

    GB/T 3984-2004 1.2UF 600VAC Power Film Capacitor

    Product Shape

    GB/T 3984-2004 1.2UF 600VAC Power Film Capacitor


    Workshop&Equipment

    GB/T 3984-2004 1.2UF 600VAC Power Film Capacitor

    Advantages Of Our Water Cooled Capacitor


    GB/T 3984-2004 1.2UF 600VAC Power Film Capacitor


    Exhibition


    GB/T 3984-2004 1.2UF 600VAC Power Film Capacitor


    Certification


    GB/T 3984-2004 1.2UF 600VAC Power Film Capacitor


    Packing Method


    GB/T 3984-2004 1.2UF 600VAC Power Film Capacitor
