0.66UF 700V Conduction Cooled Capacitor For Heat Treatment

    Buy cheap 0.66UF 700V Conduction Cooled Capacitor For Heat Treatment from wholesalers

    Buy cheap 0.66UF 700V Conduction Cooled Capacitor For Heat Treatment from wholesalers
    • Buy cheap 0.66UF 700V Conduction Cooled Capacitor For Heat Treatment from wholesalers

    0.66UF 700V Conduction Cooled Capacitor For Heat Treatment

    Ask Lasest Price
    Brand Name : GDHY
    Model Number : C41701664KTC2201-01
    Certification : SGS,ISO
    Price : 107 USD /PCS
    Payment Terms : T/T, Western Union, MoneyGram
    Supply Ability : 1000 PCS/ MONTH
    Delivery Time : 14 DAYS
    • Product Details
    • Company Profile

    0.66UF 700V Conduction Cooled Capacitor For Heat Treatment

    0.66UF 700V Conduction Cooled Capacitor For Heat TreatmentC41-TC2 0.66UF/700V/200KVAR ALCON FP-4-150-SM/SP CELEM CSM150 CAPACITORS FOR SALE MAKE INDUCTION HEATER CAPACITOR


    Technical Parameter


    Reference StandardsGB/T 3984-2004 IEC 60110.1
    Operating Temperature Range-40℃~85℃
    Capacity Range0.66μF
    Power Range200 kVar
    Rated Voltage700VAC
    Capacity Tolerance±10%
    Test Voltage between Terminals1.5UNAC 10s
    2~3.5UNDC 10s at 25℃±5℃
    Dissipation Factortgδ≤5×10-4 at 25℃±5℃,1kHz
    Insulation ResistanceR•C≥3000s,at 100VDC,25℃±5℃,60s
    Life Expectancy100000h at UN and 70℃,30000h at Urms

    Specification download: C41-TC2.pdf


    Application

    Induction heating, heat treatment, plasma applications, resonant circuits, medical imaging, wireless power transfer, EV (electric vehicle) charging, IPT, high frequency inverters,etc.


    Feature

    ● Conduction water-cooled

    ● Polypropylene dielectric

    ● Low dissipation factor(tgδ), low ESL, low ESR

    ● High voltage, high frequency and high dV/dt,

    ● Can bear large current, excellent heat dissipation


    Product Picture

    0.66UF 700V Conduction Cooled Capacitor For Heat Treatment


    Product Shape

    0.66UF 700V Conduction Cooled Capacitor For Heat Treatment

    Production Line

    0.66UF 700V Conduction Cooled Capacitor For Heat Treatment


    Workshop&Equipment

    0.66UF 700V Conduction Cooled Capacitor For Heat Treatment

    Packing Method

    0.66UF 700V Conduction Cooled Capacitor For Heat Treatment


    Certification

    0.66UF 700V Conduction Cooled Capacitor For Heat Treatment


    Exhibition

    0.66UF 700V Conduction Cooled Capacitor For Heat Treatment

    0.66UF 700V Conduction Cooled Capacitor For Heat Treatment
