Celem CSP180 0.18uF 700V 180KVar Conduction Cooled Capacitor

    Buy cheap Celem CSP180 0.18uF 700V 180KVar Conduction Cooled Capacitor from wholesalers

    Buy cheap Celem CSP180 0.18uF 700V 180KVar Conduction Cooled Capacitor from wholesalers
    • Buy cheap Celem CSP180 0.18uF 700V 180KVar Conduction Cooled Capacitor from wholesalers

    Celem CSP180 0.18uF 700V 180KVar Conduction Cooled Capacitor

    Ask Lasest Price
    Brand Name : GDHY
    Model Number : C41701184KBC3181-01
    Price : USD230/PC
    Payment Terms : T/T, Western Union, MoneyGram
    Supply Ability : 1000PCS/MONTH
    Delivery Time : 14days
    Certification : SGS,ISO
    • Product Details
    • Company Profile

    Celem CSP180 0.18uF 700V 180KVar Conduction Cooled Capacitor

    C41-BC3 0.18uF 700V 180KVar same as Celem CSP180 for hardening machine Conduction Cooled Induction Power Capacitor

    Technical Parameter

    Reference StandardsGB/T 3984-2004 IEC 60110.1
    Operating Temperature Range-40℃~85℃
    Capacity Range0.1μF~5μF
    Power Range180kVar
    Rated Voltage400-1000VAC
    Capacity Tolerance±5% ~ ±10%
    Test Voltage between Terminals1.5UNAC 10s
    2~3.5UNDC 10s at 25℃±5℃
    Dissipation Factortgδ≤5×10-4 at 25℃±5℃,1kHz
    Insulation ResistanceR•C≥3000s,at 100VDC,25℃±5℃,60s
    Life Expectancy100000h at UN and 70℃,30000h at Urms

    Application


    *Induction heating, heat treatment, plasma applications, resonant circuits, medical imaging, wireless power transfer, EV (electric vehicle) charging, IPT, high frequency inverters,etc.


    Feature


    ● Conduction water-cooled

    ● Polypropylene dielectric

    ● Low dissipation factor(tgδ), low ESL, low ESR

    ● High voltage, high frequency and high dV/dt

    ● Can bear large current, excellent heat dissipation


    Product Picture

    Celem CSP180 0.18uF 700V 180KVar Conduction Cooled Capacitor


    Product Shape


    Celem CSP180 0.18uF 700V 180KVar Conduction Cooled Capacitor


    Workshop&Equipment


    Celem CSP180 0.18uF 700V 180KVar Conduction Cooled Capacitor


    Exhibition


    Celem CSP180 0.18uF 700V 180KVar Conduction Cooled Capacitor


    Certification


    Celem CSP180 0.18uF 700V 180KVar Conduction Cooled Capacitor


    Packing Method


    Celem CSP180 0.18uF 700V 180KVar Conduction Cooled Capacitor
