Induction Heating 1200V DC 3000nF Resonant Capacitor

    Buy cheap Induction Heating 1200V DC 3000nF Resonant Capacitor from wholesalers

    Buy cheap Induction Heating 1200V DC 3000nF Resonant Capacitor from wholesalers
    • Buy cheap Induction Heating 1200V DC 3000nF Resonant Capacitor from wholesalers
    • Buy cheap Induction Heating 1200V DC 3000nF Resonant Capacitor from wholesalers

    Induction Heating 1200V DC 3000nF Resonant Capacitor

    Ask Lasest Price
    Brand Name : GDHY
    Model Number : C44501305JFF01M6-01
    Certification : SGS,ISO
    Price : USD 7.8/PCS
    Payment Terms : Western Union, T/T, MoneyGram
    Supply Ability : 1000PCS/MONTH
    Delivery Time : 14 DAYS
    • Product Details
    • Company Profile

    Induction Heating 1200V DC 3000nF Resonant Capacitor

    Induction Heating 1200V DC 3000nF Resonant CapacitorC44 3UF/500VAC/1200VDC 60A 5% METALLIC FILM CAPACITOR POLYPROPYLENE FILM EPOXY RESIN HIGH QUALITY FREE SAMNPLE ON SALE


    Technical Parameter

    Reference StandardsIEC 61071.IEC60110
    Operating Temperature Range-40℃~85℃ Tmax 105℃
    Capacity Range1μF~7μF
    Rated Voltage1200VDC~2000VDC
    Capacity Tolerance±5%(J); ±10%(K)
    Withstand Voltage1.5Un DC/10S
    Dissipation Factortgδ≤0.0010 C≤1μF f=10KHz at 20℃
    Insulation ResistanceRsC≥5000S (20℃ 100VDC 60S)
    Flame RetardationUL94V-0
    Life Expectancy100000hrs ( Un hotspot ≤ 70℃)


    Specification download: C44-small size.pdf


    Application

    • Widely used series circuits or parallel resonant circuites of power electronic devices.
    • Welding power supplies, Induction heating equipment in resonance occasions.

    Feature

    • Plastic packaging, epoxy resin filling.
    • Lead by the tinned copper nut, small size and convenient installation.
    • High-frequency and high current endurance.
    • Low ESL, low ESR.
    • High pulse current, high dv/dt ehdurance and good stability, self healing.

    Product Picture

    Induction Heating 1200V DC 3000nF Resonant Capacitor

    Induction Heating 1200V DC 3000nF Resonant Capacitor


    Product Shape


    Induction Heating 1200V DC 3000nF Resonant Capacitor


    Production

    Induction Heating 1200V DC 3000nF Resonant Capacitor


    Workshop&Equipment

    Induction Heating 1200V DC 3000nF Resonant Capacitor


    Packing method

    MKP-X2 0.33UF/310V P22.5 WIMA FKP 2/FKP 3 KEMET R4631/R463R/R463W/R463N TDK B32669 VISHAY F339M-X2 SAFETY CAPACITOR 5

    Certificate

    Induction Heating 1200V DC 3000nF Resonant Capacitor

    Exhibition

    MKP-X2 0.33UF/310V P22.5 WIMA FKP 2/FKP 3 KEMET R4631/R463R/R463W/R463N TDK B32669 VISHAY F339M-X2 SAFETY CAPACITOR 7
