40A 15UF 1200VDC High Frequency Capacitor

    Buy cheap 40A 15UF 1200VDC High Frequency Capacitor from wholesalers

    Buy cheap 40A 15UF 1200VDC High Frequency Capacitor from wholesalers
    • Buy cheap 40A 15UF 1200VDC High Frequency Capacitor from wholesalers

    40A 15UF 1200VDC High Frequency Capacitor

    Ask Lasest Price
    Brand Name : GDHY
    Model Number : C53122156JKF01M6-01
    Certification : SGS,ISO
    Price : USD 6.3/PCS
    Payment Terms : Western Union, T/T, MoneyGram
    Supply Ability : 1000PCS/MONTH
    Delivery Time : 14 DAYS
    • Product Details
    • Company Profile

    40A 15UF 1200VDC High Frequency Capacitor

    40A 15UF 1200VDC High Frequency CapacitorC53 15UF 1200VDC 10% HIGH FREQUENCY HIGH CURRENT BEARING POLYPROPYLENE FILM CAPACITOR SMALL SIZE GOOD QUALITY POWER


    Technical Parameter

    Reference StandardsGB/T 17702 IE 61071
    Operating Temperature Range-40℃~70℃ Tmax 85℃
    Capacity Range15μF
    Rated Voltage1200VDC
    Capacity Tolerance±10%(K)
    Test voltage between electrodes1.5Un DC/60S 20
    Test voltage between electrode and case1000+2X UN/√2(VAC) 50Hz 60S (min 3000VAC)
    Dissipation Factortgδ≤2X10-3 0.0010 at 20℃,1KHz
    Insulation ResistanceRsC≥5000S (20℃ 100VDC 60S)
    Life Expectancy100000hrs ( Un hotspot ≤ 70℃)


    Specification download: C53.pdf


    Application

    • Widely used DC-Link circuits, as a high frequency filtering and decoupling.
    • Direct coupling in power electronic equipment.

    Feature

    • Polypropylene film dielectric.
    • Mylar tape packaging, sealed with epoxy resin.
    • Small size and easy installation.
    • Excellent high frequency and high current bearing capacity.

    Product Picture

    40A 15UF 1200VDC High Frequency Capacitor


    Product Shape


    40A 15UF 1200VDC High Frequency Capacitor


    Production

    40A 15UF 1200VDC High Frequency Capacitor


    Workshop&Equipment

    40A 15UF 1200VDC High Frequency Capacitor


    Packing method

    MKP-X2 0.33UF/310V P22.5 WIMA FKP 2/FKP 3 KEMET R4631/R463R/R463W/R463N TDK B32669 VISHAY F339M-X2 SAFETY CAPACITOR 5

    Certificate

    40A 15UF 1200VDC High Frequency Capacitor

    Exhibition

    MKP-X2 0.33UF/310V P22.5 WIMA FKP 2/FKP 3 KEMET R4631/R463R/R463W/R463N TDK B32669 VISHAY F339M-X2 SAFETY CAPACITOR 7
