2000VDC 750VAC 50A Resonance Film Capacitor

    Buy cheap 2000VDC 750VAC 50A Resonance Film Capacitor from wholesalers

    Buy cheap 2000VDC 750VAC 50A Resonance Film Capacitor from wholesalers
    • Buy cheap 2000VDC 750VAC 50A Resonance Film Capacitor from wholesalers

    2000VDC 750VAC 50A Resonance Film Capacitor

    Ask Lasest Price
    Brand Name : GDHY
    Model Number : C46202334JP101-01
    Certification : SGS,ISO
    Price : USD 4.3/PCS
    Payment Terms : Western Union, T/T, MoneyGram
    Supply Ability : 1000PCS/MONTH
    Delivery Time : 14 DAYS
    • Product Details
    • Company Profile

    2000VDC 750VAC 50A Resonance Film Capacitor

    2000VDC 750VAC 50A Resonance Film CapacitorC46 0.33UF/2000VDC/750VAC 50A 5% RESONANCE FILM CAPACTITOR PET WRAP EXPOY RESIN WELDING MACHINE INDUCTION HEATING


    Technical Parameter

    Reference StandardsIEC 61071.GB/T17702
    Operating Temperature Range-40℃-+75℃ TMax 85℃
    Capacity Range0.33μF~6.0μF
    Rated Voltage3000VDC~10000VDC
    Capacity Tolerance±5%(J); ±10%(K)
    Withstand Voltage1.5Un DC/10S
    Dissipation Factortgδ≤0.0005 C≤1μF f=10KHz at 20℃
    tgδ≤0.0010 C≥1μF f=10KHz at 20℃
    Insulation ResistanceC≤0.33μF Rs≥30000MΩ(20℃ 100VDC 60S)
    C>0.33 μF RsC≥1000S (20℃ 100VDC 60S)
    Flame RetardationUL94V-0
    Life Expectancy100000hrs ( Un hotspot ≤ 70℃)


    Specification download: C46.pdf


    Application

    • Widely used series circuits or parallel resonant circuites of power electronic devices.
    • Welding power supplies, Induction heating equipment in resonance occasions.

    Feature

    • PET tape wrapping, epoxy resin perfusion.
    • Tin plated coppper nut or copper sheet leads.
    • High-frequency current capacity.
    • Low ESL, low ESR.
    • High pulse current, high dv/dt, high stability, self healing.

    Product Picture

    2000VDC 750VAC 50A Resonance Film Capacitor


    Product Shape


    2000VDC 750VAC 50A Resonance Film Capacitor


    Production

    2000VDC 750VAC 50A Resonance Film Capacitor


    Workshop&Equipment

    2000VDC 750VAC 50A Resonance Film Capacitor


    Packing method

    MKP-X2 0.33UF/310V P22.5 WIMA FKP 2/FKP 3 KEMET R4631/R463R/R463W/R463N TDK B32669 VISHAY F339M-X2 SAFETY CAPACITOR 5

    Certificate

    2000VDC 750VAC 50A Resonance Film Capacitor

    Exhibition

    MKP-X2 0.33UF/310V P22.5 WIMA FKP 2/FKP 3 KEMET R4631/R463R/R463W/R463N TDK B32669 VISHAY F339M-X2 SAFETY CAPACITOR 7
