2.2UF High Voltage Snubber Capacitor

    Buy cheap 2.2UF High Voltage Snubber Capacitor from wholesalers

    Buy cheap 2.2UF High Voltage Snubber Capacitor from wholesalers
    • Buy cheap 2.2UF High Voltage Snubber Capacitor from wholesalers

    2.2UF High Voltage Snubber Capacitor

    Ask Lasest Price
    Brand Name : GDHY
    Model Number : C31701225JPC1-01
    Certification : ISO,SGS
    Price : USD1.8
    Payment Terms : T/T, Western Union, MoneyGram
    Supply Ability : 1000PCS/MONTH
    Delivery Time : 14DAYS
    • Product Details
    • Company Profile

    2.2UF High Voltage Snubber Capacitor

    C31 2.2UF 700VDC Snubber Capacitor for IGBT High Voltage Snubber Capacitor


    Technical Parameter

    Reference StandardsIEC61071 .GB/T17702
    Operating Temperature Range-40℃~+85℃ (Max. +105℃)
    Capacity Range0.047μF -10μF
    Rated Voltage700 VDC -3000VDC
    Capacity Tolerance±5%(J); ±10%(K)
    Withstand voltage1.5Un Dc/10S
    Dissipation Factortgδ≤0.0005 C≤1μF f=10KHz
    Tgδ ≤ 0.0010 C≥1μF f=10KHz
    Insulation ResistanceC≥0.33μF Rs≥30000MΩ(at20℃ 100VDC 60S)
    C>0.33 μF RsC≥10000S (at20℃ 100VDC 60S)
    Flame RetardationUL94V-0
    Life Expectancy100000hrs at Un and 85℃



    Application

    *IGBT buffer absorption circuit protection; IGBT buffer absorption device.

    *Widely used in power electronic equipment UPS, inverter, induction heating, electric welding machine and other equipment peak voltage, peak current absorption protection


    Features


    ● Plastic shell, flame-retardant epoxy encapsulation

    ● Tinned copper sheet extraction

    ● Resistance to high voltage, low dissipation factor

    ● Low ESL, low ESR, low temperature rise

    ● High pulse current, high dV/dt affordability


    Product Picture

    2.2UF High Voltage Snubber Capacitor


    Product Shape

    2.2UF High Voltage Snubber Capacitor


    Product Process


    2.2UF High Voltage Snubber Capacitor


    Workshop&Equipment


    2.2UF High Voltage Snubber Capacitor

    Exhibition

    2.2UF High Voltage Snubber Capacitor


    Certification

    2.2UF High Voltage Snubber Capacitor


    Packing Method

    2.2UF High Voltage Snubber Capacitor
